DPG20C200PN
Low Loss and Soft Recovery
High Performance Fast Recovery Diode
Common Cathode
HiPerFRED2
1
2
3
Part number
DPG20C200PN
Backside: isolated
I= AFAV
2x
tnsrr
=
35
V= VRRM
10
200
Features / Advantages: Applications: Package:
TO-220FP
●
Planar passivated chips
●
Very low leakage current
●
Very short recovery time
●
Improved thermal behaviour
●
Very low Irm-values
●
Very soft recovery behaviour
●
Avalanche voltage rated for reliable operation
●
Soft reverse recovery for low EMI/RFI
●
Low Irm reduces:
- Power dissipation within the diode
- Turn-on loss in the commutating switch
●
Antiparallel diode for high frequency
switching devices
●
Antisaturation diode
●
Snubber diode
●
Free wheeling diode
●
Rectifiers in switch mode power
supplies (SMPS)
●
Uninterruptible power supplies (UPS)
●
Industry standard outline
●
RoHS compliant
●
Epoxy meets UL 94V-0
●
Soldering pins for PCB mounting
●
Base plate: Plastic overmolded tab
●
Reduced weight
●
Isolation Voltage: V~
2500
IXYS reserves the right to change limits, conditions and dimensions.
20131126a
Data according to IEC 60747and per semiconductor unless otherwise specified
? 2013 IXYS all rights reserved
